RPi Serial Connection. The kernel will use the port as controlled by kernel command line. You can use /dev/ttyAMA0 like any normal Linux serial port. This class can communicate with a Arduino board via serial port. It can open a connection with a USB serial port of a given name on Linux. The class can send and receive messages from the board. I am trying to communicate with a micro controller trough a serial port under Linux. I am using a USB to serial cable for the purpose, but my php script is giving me the following error: Fatal err.

• Debian Linux: Set a Serial Console. Which is a communication program that runs under most unices. Legacy, Linux, linux boot, Linux COM1 port, linux kernel.
• This class can communicate with a Arduino board via serial port. With a USB serial port of a given name on Linux. Class for php-Arduino communications on Linux.

I am trying to connect minicom to a serial device that is connected via a USB-to-serial adapter. This is a PL2303 and from everything I've read no additional drivers are required. The device is recognised as a PL2303.

I'm a beginner at minicom. Hp service manual laptop. Is this the correct command to execute? Or do I need to configure something?

Peter Mortensen

Linux Serial Port Read

codingJoecodingJoe

10 Answers

First check with dmesg grep tty if system recognize your adapter.Then try to run minicom with sudo minicom -s, go to 'Serial port setup' and change the first line to /dev/ttyUSB0.

Don't forget to save config as default with 'Save setup as dfl'. It works for me on Ubuntu 11.04 on VirtualBox.

MatejMatej

You will need to set the permissions every time you plug the converter in.I use PuTTY to connect. In order to do so, I have created a little Bash script to sort out the permissions and launch PuTTY:

P.S. I would never recommend that permissions are set to 777.

Peter Mortensen

The serial port communication programs moserial or gtkterm provide an easy way to check connectivity and modify /dev/ttyUSB0 (or /dev/ttyUSB1!) settings. Even though there maybe only a single USB to RS232 adapter, the n designation /dev/ttyUSBn can and does change periodically! Both moserial and gtkterm will show what port designation is relevant in their respective pull down menus when selecting an appropriate port to use.

Check out help.ubuntu.com/community/Minicom for details on minicom.

I had fix this with adduser *username* dialout. I never had this error again, even though previously the only way to get it to work was to reboot the PC or unplug and replug the usb to serial adapter.

I get get the same minicom error, 'cannot open /dev/ttyUSB0: No such file or directory'

Three notes:

1. I get the error when the device attached to the serial port end of my Prolific Technology PL2303 USB/Serial adapter is turned off. After turning on the device (an embedded controller running Linux) minicom connected fine.

2. I have to run as super user (i.e. sudo minicom)

3. Sometimes I have to unplug and plug back in the USB-to-serial adapter to get minicom to connect to it.

I am running Ubuntu 10.04 LTS (Lucid Lynx) under VMware (running on Windows 7). In this situation, make sure the device is attached to VM operating system by right clicking on the USB/Serial USB icon in the lower right of the VMware window and select Connect (Disconnect from Host).

Remember to press Ctrl + A to get minicom's prompt, and type X to exit the program. Just exiting the terminal session running minicom will leave the process running.

The Epson print head cleaning kit comes with a 1ML syringe. CC is the same as ML so a 5CC syringe is the same as a 5ML syringe. You can usually get a syringe from pet shops or feed and grain stores. Cleaning the Print Head Using the Head Cleaning utility. You can clean the print head from your computer using the Head Cleaning utility in the printer software, or from the printer itself by using the printer's control panel buttons. SEIKO EPSON CORPORATION. Cleaning the Print Head Using the Head Cleaning utility. You can clean the print head from your computer using the Head Cleaning utility in the printer software, or from the printer itself by using the printer's control panel buttons. EPSON recommends turning on the printer for at least one minute every month. Epson Printer Head Cleaning Kit International Patent M327287 ZL27.8 Do not copy! This is what you are looking for!!! Cleaning print heads on Epson printers. Epson t60 head cleaning software.

Linux Serial Port Communication

Peter Mortensen

Open Serial Port Linux

I had the exact same problem, and it was fixed by doing a chmod 777 /dev/ttyUSB0. I never had this error again, even though previously the only way to get it to work was to reboot the VM or unplug and replug the USB-to-serial adapter. I am running Ubuntu 10.04 (Lucid Lynx) VM on OS X.

Peter Mortensen

Long time reader, first time helper ;)

I'm going through the same hellish experience here with a Prolific USB <> Serial adapter and so far Linux is the easiest to get it to work.

On CentOS, I didn't need to install any drivers etc. That said,

• dmesg grep -i tty or dmesg grep -i usb showed me /dev/ttyUSB0.
• screen ttyUSB0 9600 didn't do the trick for me like it did in OSX
• minicom is new to me but it was complaining about lack of /dev/modem

However, this helped: https://www.centos.org/forums/viewtopic.php?t=21271

So install minicom (yum install minicom) then enter its settings (minicom -s).

Then select Serial Port Setup and change the Serial Device (Option A) to /dev/ttyUSB0, or whatever your device file is as it slightly differs per distro.

Then change the Bps (Option E) to 9600 and the rest should be default (8N1 Y N)

Save as default, then simply minicom and Bob's your uncle.

HTH.

I suggest that newbies connect a PL2303 to Ubuntu, chmod 777 /dev/ttyUSB0 (file-permissions) and connect to a CuteCom serial terminal. The CuteCom UI is simple intuitive. If the PL2303 is continuously broadcasting data, then Cutecom will display data in hex format

gatorbackgatorback

I just got my GUC232A cable with a molded-in PL2302 converter chip.

In addition to adding myself and br to group dialout, I found this helpful tip in the README.Debian file in /usr/share/doc/bottlerocket:

This package uses debconf to configure the /dev/firecracker symlink, should you need to change the symlink in the future run this command:

dpkg-reconfigure -pmedium bottlerocket

That will then prompt you for your new serial port and modify the symlink. This is required for proper use of bottlerocket.

I did that and voila! bottlerocket is able to communicate with my X-10devices.

Peter Mortensen

Putty on ubuntuThere is no need to install the driver for PL2303So only type the command to enable the puttySudo chmod 666 /dev/ttyUSB0DoneOpen the putty.
